Thermoset Carbon Paste (140℃, <20 ohm/sqr/25µm), 10-12 µm

 Applications:

  • Printed electronics,
  • Sensors and biosensor,
  • PV cells,
  • Membrane keyboards,
  • Energy storage devices,
  • Aautomative electronics.

Price range: $165.00 through $260.00

SKU: N/A Category:

Shipping world wide

Across the Globe

24/7 Support.

Your Questions, Answered Anytime.

Description

100 grams/165 €
250 grams/260 €
1000 grams/345 €

Contact us for tailored quotes on larger quantities & experience exceptional solutions from our experts.

Thermoset Carbon Paste (140℃, <20 ohm/sqr/25µm), 10-12 µm

Thermoset carbon paste with a single-part screen printer is a sophisticated and adaptable substance that finds extensive use in a range of energy and electronic applications. This novel carbon-based material is designed to provide excellent printability, thermal stability, and conductivity. The paste, which meets the increasing need for high-performance conductive materials, is a major breakthrough in materials science. It was created using state-of-the-art research and manufacturing procedures. At a low temperature of 140˚C, the paste should be cured in order to obtain a sheet resistance of less than 20 Ω/sqr/25µm.

Technical Properties:

Test Properties
Viscosity (Uncured) 4,000-8,000 cP
Coverage (Uncured) 350 cm2/g
Thickness (Cured) 10-12 µm
Sheet Resistance (Cured) <20 Ω/sq/mil
Adhesion 5B
Hardness 3H
Substrate PET, Glass, FR4
Screen PET, 5 µm emulsion, 100 mesh, 40 thread
Flood Speed 30 mm/s
Print Speed 45 mm/s



Additional information
gram

100 grams

,

1000 grams

,

250 grams
