Aluminum Laminated Film, Width: 400 mm, Length: 7.5 m

Applications:

Aluminum Laminated Film for Pouch Cell Case, 400 mm W x 7.5 m, L – EQ-alf-400-7.5M

Price range: $295.00 through $6,238.00

Shipping world wide

Across the Globe

24/7 Support.

Your Questions, Answered Anytime.

Description

1 set/295 €
5 sets/1412 €
25 sets/6238 €

Please contact us for quotes on larger quantities !!!

Aluminum Laminated Film for Pouch Cell Case

Width: 400 mm, Length: 7.5 m – EQ-alf-400-7.5M

This aluminum laminated film (115 µm) is used as casing material for polymer Li-Ion battery.

Technical Properties:


Polyamide (JIS Z1714) 0.025 mm (+-0.0025 mm)
Adhesive (Polyester-polyurethane) 4-5 g/m2
Aluminum foil (JIS A8079,A8021) 0.040 mm (+-0.004 mm)
Adhesive (Urethane-free Adhesive) 2-3 g/m2
Polypropylene 0.040 mm (+-0.004 mm)
Thickness 115 μm±5
Width 400 mm
Length 7.5 m
Surface quality Mat finish
Pinholes Subject to the applicable aluminum foil standard
Impurity 1 mm or less in diameter
Fish Eye 2 mm or less in diameter (clear), 1 mm or less in diameter (colored)



Additional information
pcs

1 set

,

25 set

,

5 set

Shipping & Delivery
Shipping world wide Across the Globe

Important Notes

  • Research Use Only: Nanochemazone materials are intended strictly for research and development purposes in laboratory and industrial settings.
  • No Refunds or Exchanges: All sales are final. Nanochemazone does not permit exchanges or offer refunds under any circumstances.
  • Customs & Import Responsibilities: Customs clearance, duties, taxes, and tariffs are the sole responsibility of the consignee/importer. Nanochemazone is not liable for delays, rejections, or any additional costs incurred during the customs process, and such issues will not justify order cancellations or refunds.
  • Order Cancellations: Once an order is placed, it cannot be cancelled. No refunds will be issued for cancelled or undelivered orders.
  • Indemnification: The buyer agrees to indemnify and hold harmless Nanochemazone, its affiliates, and personnel from any claims, damages, liabilities, or expenses arising from the use of its products or services.
  • Terms & Conditions: All orders and communications are subject to Nanochemazone’s standard Terms & Conditions.
