Li-Ion Battery Separator Film, Thickness: 25 μm, Width: 60 mm, Length: 500 m, 1 Roll: 500 m

Name: Li-Ion Battery Separator Film, Thickness: 25 μm, Width: 60 mm, Length: 500 m, 1 Roll: 500 m
SKU: 13103
Availability: InStock

$363.00 – $1,425.00

Applications:

Li-Ion Battery Separator Film can be used as li-ion battery separator in battery R&D.

The need for electric energy storage systems are in increasing demand. Lithium-ion batteries
represent the best option for many applications such as hybrid and electric vehicles which
require high energy density, cycle durability and charge/discharge efficiency.

Compare

Add to wishlist

SKU: N/A Categories: BATTERY EQUIPMENT, Separators For Batteries

Description
Additional information
Shipping & Delivery

Description

1 Roll/363 €
3 Rolls/975 €
5 Rolls/1425 €

Please contact us for quotes on larger quantities !!!

Li-Ion Battery Separator Film

Thickness: 25 μm, Width: 60 mm, Length: 500 m, 1 Roll: 500 m

Technical Properties:

Material	Polypropylene (PP)
Porosity	42±3 %
Thickness	25±2 μm
Width	60 mm
Areal density	13.2±1.0 g/m2
Air Permeability	350±100 s/100ml
Puncture Strength	≥400 g
Tensile Strength	MD: ≥1400 Kgf/cm2 TD: ≥130 Kgf/cm2
Thermal contraction (115℃/16H)	MD: ≤3.0 % TD: ≤0.5 %
